Design of Steel Structure BEU Question Paper Solution:- In This article, I have provided the solution of Design of Steel Structure BEU Previous year's question paper along with its Solution that might be similar and high chance of coming in BEU upcoming examination. I tried to make the solutions very simple and kept the language easy so that each and every student could understand it.
Students can easily Download the solution of Design of Steel Structure Question paper as well as the Design of Steel Structure BEU Question Paper Solution by just clicking on the Download Button available at the bottom of this page.
This Blog is to provide BEU Solutions to past year's question papers in Design of Steel Structure assisting Students in their exam preparation
Download Design of Steel Structure B.Tech 6th Semester 2022,
BEU PYQ (Previous Years Question) Papers
Download Bihar Engineering University (BEU) Previous Years Question Paper Solution
1. Choose the correct option of the following.
(a) Splices for compression members are designed for
(i) short column
(ii) intermediate column
(iii) long column
(iv) depending upon its thickness
(b) The slenderness ratio of compression members is limited to account for
(i) the effect of accidental and construction loads
(ii) They may be used as a walkway in braced roof truss system
(iii) vibrations
(iv) All of the above
(c) Pitch in bolted connection shall not be more than in tension member and in compression member.
(i) 12t, 16t
(ii) 20t, 16t
(iii) 16t, 12t
(iv) 16t, 20t
where, t = thickness of thinner plate
(d) For same load, unsupported length, and end conditions, a laced column as compared to battened column
(i)is stronger
(ii) is weaker
(iii) is equally strong
(iv) Cannot be compared
(e) The best double-angle compression member section is
(i) equal angles on same sides of gusset plate
(ii) equal angles on opposite sides of
(iii) gusset plate unequal angles with long legsback-to-back (iv) unequal angles with short legs back-to-back
(f) The maximum gauge length in bolted connection is
(i) 100+4t, where is thickness of thinner plate
(ii) 100-4t, where t is thickness of thinner plate
(iii) 4t, where t is thickness of thinner plate
(iv) 100 mm
(g) The most suitable compression member section for a roof truss is
(i) single angle
(ii) double angles placed as star
(iii) double angles placed back-to-back
(iv) tubes
(h) An ideal member is the section for compression
(i) one having a different moment of inertia about any axis through its center of gravity
(ii) one having the same moment of inertia about any axis through its center of gravity
(iii) one having a larger length
(iv) one made up of costly material
(i) The deflection of steel beams in buildings other than industrial buildings is limited to span divided by
(i) 180
(ii) 250
(iii) 300
(iv) 325
(j) In a bolted plate girder flange, the angle section used should be
(i) equal angle
(ii) unequal angle with short leg horizontal
(iii) unequal angle with long horizontal
(iv) bulb angle
All in one BEU PYQ solution PDF is Provided below
2. (a) (i) Classify the plastic, compact, and semi-compact sections. (i) Consider a T-section of flange 100 mm x 10 mm and web 150 mm x10 mm. Calculate shape factor, plastic moment, and reserve of strength. Use Fe 410 grade of steel.
(b) Design a double-cover plate butt joint using hexagonal head bolt ISO 4016-M 24x70-grade 5-6 property class C to connect two flats of size 350 mm x16 mm for maximum efficiency. Assume plate material as E250.
3. (a) A water tank is made with 10 mm thick plates. The plates are jointed by a lap joint using 18 mm dia bolts of grade 4-6 property class C at a pitch of 60 mm. Find the efficiency of the joint.
(b) The tension member of a bridge truss consists of a channel ISMC 300. Design a fillet weld connection of the channel to a 10 mm gusset plate. The member has to transmit a factored force of 800 kN. The overlap is limited to 350 mm. Use field welding.
4. (a) Differentiate between type-1 and type-2 bracket connections.
(b) A beam ISMB 350@514 N/m has to transmit a factored end reaction of 200 kN to the flange of a column ISHB 250@536-6 N/m. Design a stiffened seat connection using shop-welded fillet welds.
5. (a) Discuss in detail the design procedure for the built-up batten column.
(b) A column section ISHB 400@759-29 N/m is to be spliced. Design the splice plates and the connections using M20 bolts of product grade C and property class 4-6. Assume the column has machined ends. The factored design loads are the following:
Axial load over the column = 525 kN
Shear force 225 kN
Bending moment = 75 kN-m
6. A column of effective length is 9-3 m. It is subjected to an axial factored load of 1500 kN. Design the lacing system with site-welded connections for two channels back-to-back.
7. (a) Discuss in detail the stiffened and unstiffened seat connections.
(b) A beam ISMB 400@604-3 N/m has to transmit a factored reaction of 160 kN to the flange of a column ISHB200@392-4 N/m. Design a framed connection. Assume site welding.
8. A welded plate girder of 20 m span is subjected to the BM of 4000 kN-m and the SF of 800 kN (both are factored loads). The girder is laterally restrained. Use steel of grade Fe 410 and assume yield stress to be 250 MPa. Design the plate girder and check for bending strength.
9. (a) Why is a bracing system provided in the trusses? Why are sag rods required in roof trusses?
(b) Design a channel section purlin using the available section of ISJC only an industrial building to support galvanized corrugated iron sheet roof for the following data:
Span of truss = 10m
Spacing of truss = 5m
Spacing of purlins c / c = 1.5m
Inclination of roof = 30 degWind pressure = 2kN / (m ^ 2)
Weight of galvanized sheet = 150N / (m ^ 2)
Download All in One Solution of Design of Steel Structure
BEU Question Paper Solution
